6. SPECIFICATIONS
Parameter Value
Dimensions 118x80mm (WxH)
Weight 40 g
Operating
temperature
0..+55°C, non-condensing
Storage temperature -40..+85°C, non-condensing
Inputs Up to 64 channels TDM16 (4 lines with 16ch each)
Up to 32 channels TDM8 (4 lines with 8ch each)
Up to 16 channels TDM4 (4 lines with 4ch each)
Up to 8 channels stereo (4 lines with 2ch each)
LRCLK (left/right clock). Polarity: frame starts with falling edge
BCLK (bitclock): Data is sampled on rising edge
Outputs Up to 64 channels TDM16 (4 lines with 16ch each)
Up to 32 channels TDM8 (4 lines with 8ch each)
Up to 16 channels TDM4 (4 lines with 4ch each)
Up to 8 channels stereo (4 lines with 2ch each)
LRCLK (left/right clock). frame starts with falling edge
BCLK (bitclock): Data changes on falling edge
MCLK: 256*LRCLK
Cable lengths 30cm / 1 ft. maximum
Sample rates 44.1/48kHz
88.2/96kHz (channel count is halved)
176.4/192kHz (channel count is quartered)
Latency Interface <> Flexiverter internal: 2 samples
7. APPENDIX
7.1. Available AUX cards
At the time of writing (2021-11), the following AUX cards are available. More will
come, please check www.appsys.ch for updates.
Item Description
AUX-ADAT 16x16ch ADAT I/O (2x Toslink In+2x out). Supports also S/PDIF
AUX-ADAT-64 64x64ch ADAT I/O (8x Toslink In+8x out on external breakout box)
AUX-AES3 8x8ch AES3 I/O on 1x DB25, fully transformer isolated
AUX-AES67 64x64ch AES67 network card
AUX-DANTE 64x64ch DANTE network card
AUX-MADI-COAX 64x64ch MADI for coaxial cable (BNC connectors)
AUX-MADI-OPTO 64x64ch MADI optical, SC connector (Multimode 125um 1310 nm)
