User's Manual
5. SELF-TEST
The card can be tested for correct operation by the user. This is done using the
self-test mode, in which a special random test pattern is output on all channels.
This pattern is looped back via an external cable into the corresponding inputs,
where it is checked for consistency.
You need a special RJ45 loopback plug to test. This must have the following
pins connected:1-3-7 and 2-6-8
Turn off the FLX, and hold down Mode
button while switching on again
Press Mode again until the "CLOCK" LEDs show "INT/48kHz" in
⬤
cyan
color. The device is now in self-test mode.
The selftest should work in slide switch positions "Crossover" and "Straight" as
well as "DiGiCo" and "SC/Studer"
The "AUX" LED in the MODE sections shows the result of the self-test:
⬤
red: error/no connection
⬤
green (loopback data received ok)
Press Mode again or power off the device to exit self-test mode.
6. SPECIFICATIONS
Parameter Value
Dimensions 118x80mm (WxH)
Weight 83g
Operating
temperature
0..+55°C, non-condensing
Storage temperature -40..+85°C, non-condensing
Cable lengths Max. 70m, depending on a variety of factors.
Use high-quality Cat5 cable only. When transmission errors occur, try
reducing the cable length.
Channel count AUX-MADI-TP 64x64 @ 48kHz (56/57ch modes can be configured)
32x32 @ 96kHz (28ch mode can be configured)
16x16 @ 192kHz (14ch mode can be configured)
AUX-MADI-TP-DUAL 64x64 @ 48kHz (56/57ch modes can be configured)
64x64 @ 96kHz (28ch mode can be configured)
32x32 @ 192kHz (14ch mode can be configured)
Sample rates 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Latency Interface <> Flexiverter internal: 2 samples
Connector pinout Mode RJ45 Pin assignment
DiGiCo Straight 1:TX+, 2:TX-, 7:RX+, 8:RX-
DiGiCo Crossover 1:RX+, 2:RX-, 7:TX+, 8:TX-
SC/Studer Straight 1:TX+, 2:TX-, 3:RX+, 6:RX-
SC/Studer Crossover 1:RX+, 2:RX-, 3:TX+, 6:TX-
6
