benefit becomes apparent when a track is re-equalized to remove the previously applied

equalization. The engineer can be confident that, because of the 5500’s fully reciprocal

design, a truly flat frequency response will be restored.

1.5 Range Control

Each channel of the 5500s four-band EQs features a separate Range Control, which allows

the users to choose from several API module boost and cut specifications, detailed below:

Boost / Cut

Application

API Module Reference

+/- 2dB

Standard Equalization

550B

+/- 1dB

Higher Resolution Equalization

550D

+/- ½ dB

Mastering Equalization

550M

The range of the amplitude controls can be reduced to .5 or .25 of their stated scale, with

the Q altered identically as before. Range Control provides a means of adjusting the tonal

balance with finer resolution in an even gentler manner. This should be especially useful for

complex program as contained in stems or submixes, and is ideally suited for mastering

purposes. The combination of reduced range equalization coupled with APIs characteristic

“warmth” can be useful in helping breathing life to the sterile sound often found in digital

recordings.

1.6 Power Mute and Bypass

The 5500 features a true hard-wire bypass. In this mode, the output connector is wired

directly to the input. Shortly after power is first applied, or immediately after it is lost, a

special circuit forces this mode, so signal is never lost and power thumps are never heard.

The BYPASS button illuminates in red when the 5500 is in bypass mode, whenever either

the special circuit or the operator put it into bypass.
