527A Compressor/Limiter API
3
2.0 Overview
The 527A Compressor provides a comprehensive suite of controls:
• THRESHold: The level at which compression begins (+10dB to -20dB)
• RATIO: The amount of compression applied after threshold (1:1 to ∞:1)
• ATTACK: The time it takes for the compressor to respond (1 to 25 milliseconds)
• RELEASE: The time it takes the compressor to return to unity gain (.3 to 3 seconds)
• OUTput: Manual output level (make-up gain) control (-∞ to +10dB)
• LINK: Activates the DC link for stereo/multichannel operation with other 527A & 527 modules
• TYPE: NEW (feed-forward) or OLD (feedback) detection path topology
• KNEE: The HARD or SOFT response curve at the onset of compression.
•
THRUST
®
: Patented circuit that inserts a filter before the RMS detector
• IN/BYP: Press to toggle compression IN or out or hold to engage hard bypass (BYP)
• 10-Segment LED Meter: 10-segment LED meter (selectable gain reduction or output level)
• METER: Selects gain reduction (GR) or output (OUT) as the meter source
• OV (overload): LED peak LED (illuminates at +21dBu)
