Table of Contents
ABOUT THIS MANUAL ............................................................................................. 1
1.0 INTRODUCTION ................................................................................................ 2
2.0 OVERVIEW ........................................................................................................ 3
3.0 COMPRESSOR CONTROLS .................................................................................. 4
3.1 THRESHOLD ........................................................................................................ 4
3.2 RATIO ............................................................................................................... 4
3.3 ATTACK & RELEASE ............................................................................................... 4
3.3.1 Attack ....................................................................................................... 5
3.3.2 Release ..................................................................................................... 5
3.4 OUTPUT ............................................................................................................. 5
4.0 COMPRESSOR TYPE ........................................................................................... 6
4.1 NEW (FEED-FORWARD) ......................................................................................... 6
4.2 OLD (FEED-BACK) ................................................................................................ 6
5.0 COMPRESSOR KNEE .......................................................................................... 7
5.1 HARD KNEE COMPRESSION .................................................................................... 7
5.2 SOFT KNEE COMPRESSION ..................................................................................... 7
6.0
THRUST
®
............................................................................................................... 8
7.0 COMPRESSOR BYPASS (IN) .............................................................................. 9
8.0 DC CONTROL VOLTAGE LINK ........................................................................... 10
9.0 METERS ........................................................................................................... 11
9.1 10-SEGMENT LED METER ..................................................................................... 11
9.2 OVERLOAD LED ................................................................................................. 11
APPENDIX ............................................................................................................. 12
A1 527A SPECIFICATIONS .......................................................................................... 12
A2 527A RECALL SHEET ............................................................................................ 13
About This Manual
This manual explains the operation and applications of the “A” version of the famous API “527”
compressor/limiter. The functions and sonic qualities of the “527A” are identical to the “527,” except
the “527A” includes an improved gain reduction meter and “IN/Bypass” switch functions. Original
“527A” units can be modified so the gain reduction meter functions like the original “527.”
Legend:
UPPER-CASE BOLD = SWITCHES, BUTTONS, & POTENTIOMETERS
UPPER-CASE = REAR PANEL CONNECTIONS
Manual Revision History: YY-MM-DD format
Original: 20-07-13
Revised:
