30
Specification
General Specification
Panel
Model name Q27G4KD
Driving system OLED
Viewable Image Size 67.3 cm diagonal
Pixel pitch 0.2292mm(H) x 0.2292mm(V)
Display Color 1.07B Colors
[1]
Others
Horizontal scan range 30k~510kHz
Horizontal scan
Size(Maximum)
590.42 mm
Verticalscan range
48~500Hz
Vertical Scan Size(Maximum) 333.72 mm
Optimal preset resolution 2560 x 1440@60Hz
Max resolution 2560 x 1440@500Hz
[2]
Plug & Play VESA DDC2B/CI
Power Source 100-240V~ 50/60Hz 2A
Power Consumption
Typical(default brightness and contrast) 85W
Max. (brightness = 100, contrast =100) ≤115W
Standby Mode
≤0.5W
Physical
Characteristics
Connector Type
HDMI2.1x2/DisplayPort2.1/USB UP/USB-Ax2 (include 1 fast
charge)/Earphone
Signal Cable Type Detachable
Environmental
Temperature
Operating 0°C~40°C
Non-Operating -25°C~55°C
Humidity
Operating 10%~85% (Non-Condensing)
Non-Operating 5%~93% (Non-Condensing)
Altitude
Operating 0m~5000m (0ft~16404ft)
Non-Operating 0m~12192m (0ft~40000ft)
Note:
[1]The maximum number of display colors supported by this product is 1.07 billion, and the setting conditions
are as follows (there may be differences due to the output limitation of some graphics cards)
(“V”:support, “\” :nonsupport):
HDMI2.1 DisplayPort2.1
YCbCr420
YCbCr422
YCbCr444
RGB
YCbCr420
YCbCr422
YCbCr444
RGB
QHD 500Hz 10bits
support(DSC) support(DSC) V V
QHD 500Hz 8bits
support(DSC) support(DSC)
V V
QHD 360Hz 10bits
V V V V
QHD 240Hz 10bits
V V V V
QHD 165Hz 10bits
V V V V
Low Resolution 10 bpc
V V V V
Low Resolution 8 bpc
V V V V
Note: The DisplayPort 2.1 interface supports UHBR20 with a total bandwidth of 80 Gbps, and the HDMI 2.1
interface supports FRL6 with a total bandwidth of 48 Gbps.
Signal Version
Color Format
State
Color Bit
