25
Specification
General Specification
Panel
Model name CQ27G4ZH
Driving system TFT Color LCD
Viewable Image Size 68.5 cm diagonal
Pixel pitch 0.2331mm(H) x 0.2331mm(V)
Video HDMI lnterface & DisplayPort Interface
Display Color 1.07B Colors
[1]
Others
Horizontal scan range
30k-450kHz
Horizontal scan
Size(Maximum)
596.736mm
Verticalscan range 48-300Hz
Vertical Scan Size(Maximum) 335.664mm
Optimal preset resolution 2560X1440@60Hz
Max resolution 2560X1440@300HZ
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz, 1.5A
Power Consumption
Typical(default brightness and contrast) 35W
Max. (brightness = 100, contrast =100)
≤66W
Standby Mode ≤0.5W
Physical
Characteristics
Connector Type
HDMIx2/DisplayPort/Earphone out
Signal Cable Type Detachable
Environmental
Temperature
Operating 0°C~40°C
Non-Operating -25°C~55°C
Humidity
Operating 10%~85% (Non-Condensing)
Non-Operating 5%~93% (Non-Condensing)
Altitude
Operating 0m~5000m (0ft~16404ft)
Non-Operating 0m~12192m (0ft~40000ft)
Note:
[1]: The maximum number of display colors supported by this product is 1.07 billion, and the setting conditions
are as follows (there may be differences due to the output limitation of some graphics cards),
(“V”:support, “\” :nonsupport):
HDMI2.1 DisplayPort1.4
YCbCr422
YCbCr420
YCbCr444
RGB
YCbCr422 YCbCr420
YCbCr444
RGB
2560x1440 300Hz 10bpc \ V V \ V
2560x1440 300Hz 8bpc \ V V \ V
2560x1440 270Hz 8bpc \ V V \
V
2560x1440 270Hz 8bpc \ V V \ V
2560x1440 240Hz 10bpc \ V V \ V
2560x1440 240Hz 8bpc \ V V \ V
2560x1440 200Hz 10bpc \ V V \ V
2560x1440 200Hz 8bpc \ V V \ V
Signal Version
Color Format
State
Color Bit
