24
Specification
General Specification
Panel
Model name 24G11ZE
Driving system TFT Color LCD
Viewable Image Size 60.5 cm diagonal
Pixel pitch 0.2745mm(H) x 0.2745mm(V)
Display Color 16.7M Colors
Others
Horizontal scan range 30k~280kHz
Horizontal scan
Size(Maximum)
527.04 mm
Verticalscan range 48~240Hz
Vertical Scan Size(Maximum) 296.46 mm
Optimal preset resolution 1920x1080@60Hz
Max resolution 1920x1080@240Hz
Plug & Play VESA DDC2B/CI
Power Source
Power Consumption
Typical(default brightness and
contrast)
30W
Max. (brightness = 100, contrast
=100)
≤34W
Standby Mode ≤0.3W
Physical
Characteristics
Connector Type HDMI/DisplayPort/Earphone out
Signal Cable Type Detachable
Environmental
Temperature
Operating 0°C~40°C
Non-Operating -25°C~55°C
Humidity
Operating 10%~85% ( Non-Condensing)
Non-Operating 5%~93% ( Non-Condensing)
Altitude
Operating 0m~5000m (0ft~16404ft)
Non-Operating 0m~12192m (0ft~40000ft)
[1]
12V 2.5A
[2]
[2]
[1] A resolution of 1920x1080@240Hz is overclocking. If any error occurs to the monitor during the
overclocking process, adjust the refresh rate to 200Hz.
[2] The power specifications refer to the power consumption of the monitor (including the power
adapter) measured at the input end of the power adapter.
