Antelope Audio Zen Quadro Synergy Core User Manual
Page 70
Edge Duo is a dual-membrane condenser microphone – it has one capsule with dual
membranes and connects with a Y-XLR cable (included), one XLR connector for each
membrane. The Left (white) connector is the front membrane, the Right (red) is for the rear
membrane.
The microphone occupies two physical mic preamp inputs and two ‘EMU MIC’ virtual outputs.
Note: You can use Edge Duo as a single-membrane condenser mic by disconnecting one of
the XLR connectors. In this case, the mic emulations will be visible, but they won’t function
correctly - you cannot swap inputs and you cannot adjust polar pattern.
• Route the “PREAMP” channels for Edge Duo to your Desired outputs to monitor “dry”
audio. Route to ‘USB 1 I/O’ or ‘USB 2 I/O’ to record from the corresponding input in
your DAW.
• Route the “EMU MIC” channels for Edge Duo (same number as the “PREAMP” channels
) to your desired outputs to monitor “mic emulation” audio. Route to ‘USB 1 I/O’ or
‘USB 2 I/O’ to record from the corresponding input in your DAW or mobile device.
• Route “PREAMP” and “EMU MIC” channels to your desired outputs and ‘USB 1 I/O’ or
‘USB 2 I/O’ inputs to monitor and record both “dry” and “mic emulation” audio.
For more information about Edge Duo, visit its
product page.
Verge
Verge is a small-diaphragm condenser microphone that’s as simple to use as the Edge Solo.
Its dimensions and ability to handle high sound pressure levels make it a better fit for
positioning in tight spaces and recording very loud sources, such as drum kits.
