Antelope Audio Zen Quadro Synergy Core User Manual
Page 54
When you open your DAW, create a new track, and assign it to record audio from 'Input 1',
you will get the audio from mixer Channel 1.
Channel 1 of
which
mixer mirrors the signal which is going to each of the three virtual mixers -
their audio inputs and Synergy Core FX chains.
We are only taking the signal source and Synergy Core FX into your DAW - not the virtual
mixer outputs. This means audio is routed to your DAW before it reaches any of the virtual
mixers' pan and volume controls, so they don't get in the way of recording and mixing in
your DAW.
While working inside your DAW, you presumably want to hear its Master bus output instead of
the virtual mixers' output through your monitoring equipment. Your DAW's Master bus output,
as well as your system audio output, are always routed to USB 1 PLAY' outputs 1 and 2.
Use the channel Selectors to assign 'USB 1 PLAY' channels 1 and 2 to a pair of mixer channels
in 'Monitors & Headphones' view and mute the rest of the channels from the 'Monitor/HP1'
mixer controls. Audio from the muted channels will only be heard through your DAW's Master
bus, which is now routed to your monitoring equipment.
The rest of the 'USB PLAY ' 3 - 16 channels receive audio from DAW Outputs 3 - 16. Thus, if
you want to send an audio track from your DAW to any of the interface's analog and digital
outputs, and/or into the Synergy Core FX processing - assign this track to Output 3 – 16 in
your DAW, switch to the Control Panel application, and assign the 'USB 1 PLAY channel with
the matching number anywhere you want.
Note that the channel Selectors and AFX areas from 'Monitors & Headphones' view are
mirrored in 'USB 1 I/O' view. This way, you can clearly see which audio input you are recording
from each channel, what Synergy Core FX are being applied to it (if any) and make changes
without having to switch between views.
Loopback Function – The channel Selectors in 'USB 1 I/O' view have two additional choices:
'LOOPBACK HP1/MON' 1 - 2 and 'LOOPBACK HP2' 1 - 2. These choices let you return the 2-
channel stereo outputs from two of the three virtual mixers in 'Monitors & Headphones' view
into your DAW or streaming application. This feature can be useful in many scenarios where
