Antelope Audio Zen Quadro Synergy Core User Manual
Page 47
the 'Headphones 2' tab. The third mixer is routed to the Line outputs 1 and 2 on the interface's
rear panel and is accessed from the 'Line Out' tab.
Important! The three mixers share their audio inputs and applied Synergy Core FX, but the
pan controls, volume faders, and Solo/Mute/Link controls are individual for each.
From top to bottom, the 'Monitors & Headphones' view is organized as follows:
Input selectors
Each mixer channel has its own audio input selector found above it. The inputs are colorq-
coded. Click on an input selector to make your choice. The following inputs are available:
PREAMP 1 - 4
Analog inputs A2 - A4
EMU MIC 1 - 4
Analog inputs A3 - A4 with Antelope Audio
Edge & Verge Mic Emulations applied. This
way, you can monitor and record 'dry'
microphone audio from PREAMP 3 - 4 and
'mic emulation' microphone audio from EMU
MIC 3 - 4 on different mixer and DAW
channels.
USB 1 PLAY 1 - 16
Those are the computer playback channels
from the USB 1 port. Assign an audio track
to Output 1 – 16 in your DAW and choose the
USB 1 PLAY input with the same number
from the input selector. This way, you can
route DAW audio to the interface's outputs
and treat it with Synergy Core FX.
