Discrete 4 Pro Synergy Core User Manual

Page 60

1. Open the Control Panel and head to the leftmost preamp from the PREAMPS row.

Click the middle symbol to the right of the volume indicator until you reach the 'mic'

symbol. Then, click the 'cog wheel' symbol. This will launch the mic emulations window.

Choose Edge Duo with the dial.

2. Adjust microphone gain with the gain knobs. Note that preamps A1 and A2 are now

linked and have identical settings between them.

3. Go to any available mixer, ‘MIXER 1’ in this example, and select ‘EMU MIC 1’ and ‘EMU

MIC 2’ as sources for the first two, or any other mixer channels.

4. Open the ‘HEADPHONES 1’ tab on the bottom of the control panel and make sure the

outputs of the first mixer are selected from the left and right channel dropdown menus,

‘MIXER 1 OUT 1’ and ‘MIXER 1 OUT 2’ respectively.

You should be hearing mic audio in your headphones at this point. Use the

‘HEADPHONES 1’ volume knob or the mix faders for Channels 1 and 2 to adjust output

volume.

Gain Calibration

Gain adjustment for the Edge Solo and Verge is straightforward, but the Edge Duo and

Edge Quadro are multi-membrane microphones. There may be differences in the input

signal strength from each membrane, which is to be expected due to the opposite

directions of the capsules.

Note that engaging mic emulations for Edge Duo and Edge Quadro automatically ‘links’

their input channels, thus individual gain adjustments per input are not possible while

using their mic emulations.

Using Mic Emulations
