8
Pin
Function
1
Ground
2
Data-
3
Data+
DMX Operation
Making the DMX Connection – Connect the machine to a DMX controller or to one of the
machines in the DMX chain. The machine uses a 3-pin or 5-pin XLR connector for DMX
connection, the connector is located on the front of the machine.
Address Setup – Use control menu to set DMX address. The machine occupies 2 control
channels. The starting address is defined as the first channel from which the machine will
respond to the controller. Always double check to make sure there are no overlapping
channles in order to control the machine correctly.
DMX Channel Function
Channel 1
DMX Value Range
Function
Faze Output Level
0 – 4
Faze Off
5 – 255
Faze Output 1 – 100%
Channel 2
DMX Value Range
Function
Fan Output Level
0 – 4
Fan 20%
5 – 255
Fan 21 – 100%
