PACKAGE : Optimo Ultra 12x S35 & shperical kit
16
2 - TECHNICAL SPECIFICATIONS
2 - TECHNICAL SPECIFICATIONS I SPECIFICATIONS TECHNIQUES
ANGENIEUX OPTIMO ULTRA 12x
CONFIGURATION
S35
U35 FF/VV
Zoom ratio 12x 12x 12x
Focale Length (mm) 24-290 26-320 36-435
Maximum aperture T2.8 T3.1 T4.2
Minimum Object Distance (ft) 4’ 4’1’’ 5’
Image coverage (mm) 31.1 34.6 46.3
Weight (kg / lbs) 12.6 / 27.7 12.75 / 28.1 12.75 / 28.1
Front diameter (mm) 162.0
Max diameter (mm) 171
Length (front to mount) (mm) 473 482 523
Mounts PL
Internal focus Yes
Iris scales 2 opposite scales
Angular rotation of iris ring (°) 90
Iris gear drive 132 teeth, pitch 32
Zoom scales 2 opposite scales
Angular rotation of zoom ring (°) 170
Zoom gear drive 183 teeth, pitch 32
Focus scales 2 opposite scales, metric or footage marked
Angular rotation of focus ring (°) 320
Focus gear drive 208 teeth, pitch 32
Angular eld of view (for lm 35mm : 22x16mm)
Focale Length (mm) 24 290 26 320 36 435
Horizontal angular FOV (°) 48.2 4.4 43.7 4.0 32.7 2.9
Object size at MOD (mm) 538x732 47x65 478x666 42x58 462x640 41x56
Angular eld of view (for lm S35mm : 24.9x18.67mm)
Focale Length (mm) 24 290 26 320 36 435
Horizontal angular FOV (°) 54.0 5.0 49.1 4.5 36.9 3.3
Object size at MOD (mm) 632x860 55x73 560x760 49x65 541x728 48x63
