10 OPTIMO 28-76 1 - GENERAL SPECIFICATIONS
1 - GENERAL SPECIFICATIONS
Angénieux OPTIMO 28-76
Zoom ratio 2.7x
Focal length 28 - 76mm
Maximum Aperture T2.6 – f/2.4
Minimum Object Distance (MOD) 0.61 m - 2’
Image coverage S35+ : 31.4mm diagonal
Weight 1.92kg - 4.4 lbs
Front Diameter 114 mm
Iris scales 2 opposite scales, whole and 1/3 stop marked T2.6 – T22
Angular rotation of iris ring 90 degrees
Iris gear drive 105 teeth, pitch 32
Zoom scales 2 opposite scales
Angular rotation of zoom ring 170 degrees
Zoom gear drive 105 teeth, pitch 32
Focus scales 2 opposite scales, metric or footage marked
Angular rotation of focus ring 320 degrees
Focus gear drive 111 teeth, pitch 32
Angular field of view (for 35mm academic film size: 22x16mm)
Focal length 28mm 76mm
Horizontal angular FOV 42.8° 16.4°
Object size at MOD 345x246mm 126x92mm
