10 OPTIMO 15-40 1 - GENERAL SPECIFICATIONS
1 - GENERAL SPECIFICATIONS
Angénieux OPTIMO 15-40
Zoom ratio: 2.7x
Focal length: 15-40mm
Aperture: T2.6 - f/2.4
Minimum Object Distance (MOD): 0.61 m - 2’
Image coverage: S 35 +: 31.4 mm diagonal
Weight : 1.92kg - 4.4 lbs
Front Diameter: 114 mm
Iris scales: 2 opposite scales, whole and 1/3 stop marked
Angular rotation of iris ring: 90 degrees
Iris gear drive: 105 teeth, pitch 32
Zoom scales: 2 opposite scales
Angular rotation of zoom ring: 170 degrees
Zoom gear drive: 105 teeth, pitch 32
Focus scales: 2 opposite scales, metric or footage marked
Angular rotation of focus ring: 320 degrees
Focus gear drive: 111 teeth, pitch 32
Angular field of view (for 35mm academic film size: 22x16mm)
Focal length 15mm 40mm
Horizontal angular field of view 73° 31.2°
Object size at MOD 611x437mm 230x169mm
