Type EZ3 S35 (Tele)
S35-3 perf FF/Vista Vision
Imaging coverage Up to 30.4 mm Up to 46.3 mm
Zoom ratio 3.7x 3.7x
Focal length 45 165 mm 68 250 mm
Aperture f/2.3 - T3.0 F/3.5 - T4.5
MOD 4ft - 1.2 m 4ft - 1.2 m
Reference image size 24x13.5 mm² 37.7x24.9 mm²
Horizontal angular FOV 30° - 8.4° 31.1° - 8.6°
Vertical angular FOV 16.8° - 4.8° 20.5° - 5.8°
FOV at MOD at focal min 549 x 150 mm² 570 x 154 mm²
FOV at MOD at focal max 303 x 80 mm² 370 x 103 mm²
Front diameter 114 mm 114 mm
Length 265 mm 265 mm
Weight 5.7 lb - 2.6 kg 5.7 lb - 2.6 kg
Technical specication EZ3 particular specication
Les EZ-3 have a linear ramping :
• From F135mm in S35 (max ramping at F165 : 2/3 T-Stop)
• From F200mm in FF (max ramping at F250 : 2/3 T-Stop)
The ramping is only here when the aperture is under T3 (S35) or T4.5 (FF).
The rest of the time the EZ-3 have a constant aperture.
Iris ring setting
Iris ring setting
