Chapter 1: Introducing Your New N1512 Windowing Processor
7
N1512 Windowing Processor User Manual
TABLE 1 Front and Rear Panel Descriptions
Front Panel
POWER LED On solid (green) when operating power is supplied (via local power supply).
STATUS LED On green signifies CPU activity/status.
Rear Panel
Power Input 120 or 230VAC (auto-sensing)
Reset Button Recessed pushbutton. Press to initiate a “warm restart” which causes the processor to reset, but not lose
power. A reset does NOT affect the current settings. Press and hold for 30 seconds to perform a factory
restore.
Diagnostic LEDs LEDs 0-3
Lower row: On solid green signifies receipt of active input stream.
Upper row: Blinking green signifies input processor activity.
LED 4
Upper and Lower: N-Series diagnostics.
LED 5
Upper row: Blinking green signifies CPU activity/status.
Lower row: Blinking green signifies output processor activity/status.
P0-P2 Ports 8-wire RJ45 female.
10/100/1000 Mbps 10/100/1000Base-T auto-sensing gigabit Ethernet switch port.
U0-U3 Ports 8-wire RJ45 female.
1000Base-T gigabit Ethernet port.
