Chapter 3: Windowing Processor Configuration Options
19
N1512 Windowing Processor User Manual
Crop/Pan/Zoom Page
Click the Crop/Pan/Zoom link at the top of any of the main web pages to access the page shown in Figure 10. This page allows you
to access finer control of the individual windows. See Table 3
for option descriptions.
FIG. 10
Crop/Pan/Zoom Page
TABLE 3 Crop/Pan/Zoom Page Options
Option Description
Window Number tabs
(1-4)
Select the window for which you would like to view/edit settings.
X1, Y1 Set pixel coordinates of cropping area (top left).
X2, Y2 Set pixel coordinates of cropping area (bottom right).
Resolution Displays the current window’s resolution.
Aspect Ratio checkbox Enable Aspect Ratio to restrict crop box re-sizing so that the cropped portion maintains the aspect ratio of the
original resolution.
Cancel button Click to return all controls to the last saved configuration.
Take bu tto n Click Ta ke to apply setting changes.
