HPX-1600 Hydraport
2
HPX-1600 Retractable Connection Port
Product Specifications
HPX-1600 Specifications
Dimensions (HWD):
Max above mounting surface: 9.57" x 10.55" x 4.53" (243mm x 268mm x 115mm)
Max below mounting surface: 15.08" x 11.54" x 6.26" (383mm x 293mm x 159mm)
Min. mounting surface thickness: 19mm (.75in)
Max mounting surface thickness: 50mm (2.0in)
Weight:
Base Assembly only: 2 Kg (4.41 lbs)
Typical Installation: 3 Kg (6.61 lbs)
Models Available: • International, Black trim (FG550-BL)
• International, Silver trim (FG550-SL)
• North American, Black trim (FG550-01-BL)
• North American, Sliver trim (FG550-01-SL)
Enclosure Natural finish metal frame with plastic top and bottom covers moving ver-
tically in a plastic sleeve assembly.
• Matt black top cover and trim ring (FG550-BL, FG550-01-BL) or matt
silver top cover and trim ring (FG550-SL, FG550-01-SL).
• Matt black module face plates on all I/O modules.
Rear Connections • Included rear connection – IEC 320 C14 Power cord receptacle
(FG550-BL, FG550-SL), Included AC Power Cord (FG-550-01-BL,
FG550-01-SL).
• Rear connections for individual modules are routed through openings in
the unit’s bottom cover.
Compatibility: • HPX-P200-US, Hydraport Power Outlet Module – US (FG551-01)
• HPX-P200-UK, Hydraport Power Outlet Module – UK (FG551-11)
• HPX-P200-EU, Hydraport Power Outlet Module – EU (FG551-21)
• HPX-P200-AU, Hydraport Power Outlet Module – AU (FG551-31)
• HPX-AV100-CS+A, Hydraport Composite with Stereo Module
(FG552-10)
• HPX-AV100-RGB+A, Hydraport RGBHV with Stereo Module
(FG552-11)
• HPX-C5400-CS+A, Hydraport Composite + Stereo UPX CAT5 Kit with
HPX carrier (FG552-50-BL-K)
• HPX-C5400-VGA+A, Hydraport RGBHV + Stereo UPX CAT5 Kit with
HPX carrier (FG552-51-BL-K)
• HPX-C5400-CN+A, Hydraport Component + Stereo UPX CAT5 Kit with
HPX carrier (FG552-52-BL-K)
• HPX-N100-RJ45, Hydraport Single RJ45 Module (FG553-01)
• HPX-N102-RJ45, Hydraport Dual RJ45 Module (FG553-02)
• HPX-N100-USB, Hydraport Single USB Module (FG553-11)
• HPX-U100-BTN, Hydraport Single Button Module with LED (FG554-01)
• HPX-U400-MET-6N, Hydraport Metreau 6N Kit with HPX Carrier
(FG554-11-BL-K)
• HPX-U400-MET-13, Hydraport Metreau 13 Kit with HPX Carrier
(FG554-12-BL-K)
• HPX-U400-MET-7, Hydraport Metreau 7 Kit with HPX Carrier
(FG554-13-BL-K)
• HPX-U400-SP-08-AX, Hydraport Novara AxLink 8-button Module
(FG554-51-BL)
• HPX-U400-CP-1008, Hydraport Novara ControlPad 8-button Module
(FG554-71-BL)
• HPX-U200-MOD, Hydraport Modero Connection Module (FG554-81)
