Product Overview and General Specifications
13
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Enova DGX DXLink Twisted Pair Boards* (page 93)
* DXLink Twisted Pair Boards must be used in conjunction with DXLink Twisted Pair Transmitters and Receivers or other
AMX DXLink signal management solutions. For model numbers of compatible Transmitters and Receivers, see page 95.
For system setup information, see page 99.
Enova DGX DXLink Fiber Boards** (page 108)
** DXLink Fiber Boards must be used in conjunction with DXLink Fiber Transmitters and Receivers. For model numbers of
compatible Transmitters and Receivers, see page 110. For system setup information, see page 116.
Epica DGX SC Optical Boards^ (page 131)
^ Epica DGX SC Optical Boards work in Enova DGX enclosures and must be used in conjunction with DGX Fiber
Transmitters and Receivers. For model numbers of compatible modules, see page 132. For system setup information,
see page 133.
^^ The SC Optical Input Board FG1056-505 is compatible with the Enova DGX 8/16/32/64, replacing SC Optical Input
Board FG 1056-500 (discontinued) which was compatible with the Enova DGX 8/16/32 only.
Enova DGX Expansion Boards
Enova DGX Switchers currently support the Audio Insert/Extract Board. This board can be installed in either or both
of the expansion slots. The Audio Insert/Extract Board will not fit in a standard input or output board slot.
Enova DGX Audio Insert/Extract Board (page 136)
^^^ AIE Board FG1058-705 is compatible with the Enova DGX 8/16/32/64, replacing AIE Board FG1058-700 (discontinued)
which was compatible with the Enova DGX 8/16/32 only.
Product Notes
The Enova DGX Digital Media Switcher includes an integrated NetLinx Central Control Processor, supports
InstaGate Pro
®
, DXLink™ Technology, and SmartScale
®
on every output, and manages and distributes analog and
digital audio and video including HDMI/HDCP, control, and Ethernet.
The Enova DGX Switcher is available as a custom system, which means it can be ordered in input to output
configuration sizes that fit your installation and contain an assortment of input, output, and expansion boards in a single
enclosure.
Note: Because Enova DGX Switchers are available as custom systems, the illustrations in this manual may
differ from the model(s) you purchased.
Type Part # Model
DXLink Twisted Pair Input FG1058-570 DGX-I-DXL
DXLink Twisted Pair Output FG1058-580 DGX-O-DXL
Type Part # Model
DXLink Multimode Fiber Input Board, Duplex FG1058-622 DGX-I-DXF-MMD
DXLink Multimode Fiber Output Board, Duplex FG1058-632 DGX-O-DXF-MMD
DXLink Single Mode Fiber Input Board, Duplex FG1058-620 DGX-I-DXF-SMD
DXLink Single Mode Fiber Output Board, Duplex FG1058-630 DGX-O-DXF-SMD
DXLink Multimode Fiber Input Board, Simplex FG1058-623 DGX-I-DXF-MMS
DXLink Multimode Fiber Output Board, Simplex FG1058-633 DGX-O-DXF-MMS
DXLink Single Mode Fiber Input Board, Simplex FG1058-621 DGX-I-DXF-SMS
DXLink Single Mode Fiber Output Board, Simplex FG1058-631 DGX-O-DXF-SMS
Type Part # Model
SC Optical Input FG1056-505 AVS-EPDGX32-OI-SC
SC Optical Output FG1056-510 AVS-EPDGX32-OO-SC
Type Part # Model
Audio Insert/Extract FG1058-705^^^ DGX-AIE
