5
Functions
1) Interchangeable Microphone Head
2) LCD Screen (see below)
3) Power / Mute Control Switch (see below)
4) Select Button (see below)
5) Microphone Input Sensitivity Adjustment—is used
to set the gain of microphone. If you are a soft talking
speaker you will need to turn the control counter clock-
wise. Turn clockwise if you are a loud talker. Use plastic
screwdriver that is supplied.
S1695 WIRELESS HANDHELD MICROPHONE for MODEL SW223A /SW224A
TURN ON MICROPHONE: Push and hold the “POWER/
MUTE” (3) button until LCD screen lights up.
TO MUTE: Press “POWER/MUTE” button twice to MUTE. Channel
number will flash when muted. Press button again twice to remove
“MUTE”.
TURN OFF MICROPHONE: Push and hold the “POWER/MUTE” (3)
button for 2 seconds to turn microphone “OFF”.
SELECT CHANNEL: Press and hold the “SELECT” (4) button for
2 seconds until you only see the word Channel and channel num-
ber. To change channel, when flashing, press the “SELECT” (4)
button until you reach the desired channel. Flashing will stop after
10 seconds and channel is now set.
LOCK / UNLOCK CHANNEL: Push the “POWER/MUTE” (3)
button and “SELECT” button at the same time to lock or unlock
channel. When locked, channel cannot be changed. “LOCKED”
symbol appears in upper left-hand corner.
Microphone Operation and Status Display
BATTERIES
1. Hold the body of microphone in hand and twist
off bottom section of microphone.
2. Insert two “AA” batteries.
3. Twist bottom section back on to microphone.
BATTERY STATUS
The life expectancy of the two batteries is about 10
hours. When the “BATTERY” symbol on the dis-
play screen keeps flashing the batteries should be
replaced immediately
WARNING ! Microphone channel selected must match the same channel number
on the wireless microphone receiver or microphone will not work (SEE #16 ON PAGE 6).
