BACK PANEL
• POWER SWITCH B : Press to turn ON. Power LED and
Battery Status Meter H will light.
• MASTER VOLUME C : Rotate knob clockwise to
increase volume of PA to desired level.
• LINE / MICROPHONE ,VOLUME / TONE CON-
TROLS : Work separately from MASTER VOLUME.
• Rotate knob clockwise to increase VOLUME. Turn TONE
knob counter-clockwise for more bass or clockwise for more
treble.
• LINE IN / OUT : 3.5mm jacks for other audio devices.
Use LINE OUT when using cable to connect to the S1274
REMOTE COMPANION SPEAKER.
• BATTERY CHARGER / DC IN : To charge the battery,
connect the PA to 110-220VAC using the supplied
power cord and AC Adapter. The battery will charge when
unit is operating with AC power, HOWEVER, the unit will
charge faster with the power switch in the “off”
position. Charging time is about 7 hours.
The PA should be plugged in and charging when not in
use to maximize battery life. Recharging the PA only
when the battery status light is orange or red will short-
en the useful life of the batteries.
• BATTERY STATUS METER : The color of the light indi-
cates the condition of the battery. Red – battery low, re-
charge immediately; Yellow/Orange – battery at 50%
should be recharged before use. Green - fully
charged.
A full charge should give you up to 10 hours of
operating time ( less if using for music).
• USB CHARGING : A 5V, 500mA charging connector
has been provided to help maintain your battery in a cell
phone, tablet or computer while in use with the PA speaker.
AUDIO CONTROLS
BLUETOOTH
AUDIO CONTROLS
16 CHANNEL DIGITAL
WIRELESS RECEIVER
B
C
D
E
F
G
H
I
J
D
• WIRED MICROPHONE INPUT : Combination XLR / ¼″
connector (this jack will accept either type microphone). If
you plug in a line level device into mic level the sound will be
loud and distorted. A microphone with an XLR connector is
typically Mic Level. A microphone with a 1/4" connector is
typically Line Level.
• PHANTOM POWER : When using a Phantom
Microphone press button to activate circuitry.
• EXTERNAL SPEAKER JACK : 1/4" output jack. Use for
connecting to a PASSIVE SPEAKER.
• SIREN BUTTON : Single - Variable tone @125 dB.
Push and hold.
QUICK SET-UP GUIDE
Instructions, when this manual
cannot be found.
E
G
F
I
J
H
K
L
K
L
M
M
UHF ANTENNA CONNECTOR
