10
INSTALLATION
Making the worktop recess hob
l Worktop thickness should be 28 - 40 mm, while its width at least 600 mm. The worktop
must be at and level. Edge of the worktop near the wall must be sealed to prevent ingress
of water or other liquids.
l There should be sucient spacing around the opening, in particular, at least 50 mm di-
stance to the wall and 60 mm distance to the front edge of worktop.
l The distance between the edge of the opening and the side wall of the furniture should
be minimum 55 mm.
l Worktop must be made of materials, including veneer and adhesives, resistant to a tem-
perature of 100°C. Otherwise, veneer could come o or surface of the worktop become
deformed.
l Edge of the opening should be sealed with suitable materials to prevent ingress of wa-
ter.
l Worktop opening must cut to dimensions as shown on gure 1.
1
50
560
490
600
592
522
min 5
max 44
Pyta grzejna 4-polowa szeroko 592 mm indukcja 3.0
30mm
min 650mm
min 650mm
30mm
min.50mm
min.84mm
min.3mm
min.69mm
min 650mm
30mm
