Wiring diagram
Note: For each connection the protective conductor must be connected to the
terminal marked .
Type /
Conductor
cross sec-
tion
Fuse protec-
tion
1
For a 230V network, single phase
connection with a neutral lead, L1
and L2 terminals bridged, neutral
lead is connected to N terminal, and
the protective conductor to
1N~
HO5VV-FG
3x4 mm²
min. 30A
2
For a 230/400V, two phase connec-
tion with a neutral lead, neutral lead
is connected to N terminal, and the
protective conductor to
2N~
HO5VV-FG
4x2,5mm²
min. 16A
