12
INSTALLATION INSTRUCTIONS
KMG* / PGA 4.1*
● prepare an opening in the worktop of a kitchen cabinet, as per the installation drawing
● connect the hob to a gas and electrical system in accordance with the instructions supplied,
● loosely attach xing brackets to the bottom of the hob*
● remove dust from the worktop, insert hob into the opening and press in rmly,
● position xing brackets (Fig.) perpendicularly to the hob's edge and tighten rmly*
● once you install the hob in the worktop, check if it operates, especially the ame failure
cut-o and igniter.
1 - Worktop
2 - Screw
3 - Bracket
4 - Hob
5 - Seal
The hob has a permanent power cord with an earthing lead. It can be only connected to an
earthed 230 V ~ 50 Hz socket. The electrical system to which the appliance is to be con-
nected must be protected with a 16 A fuse.
490
min
40
min
70
145
259
145
257
560
54
321
*optional
