11
INSTALLATION
Do not install the hob above the oven
without ventilation.
Route electrical lead so that it does not
touch the lower guard.
Installing hob in kitchen cabinet worktop
above oven.
Assembly of the gasket
Depending on the model, the seal is already installed at the factory (g.1)
If the seal has not been tted at the factory, proceed as follows:
Before installing the hob in the cut-out worktop, the gasket is to be attached to the back of
the hob (pic. 2)
To do this, rst peel o the protective lm from the self-adhesive seal and glue the gasket as
close as possible to the outer edge of the hob (g. 3,4).
1 32
USZCZELKA
KLEJ
4
Do not install the appliance without the
foam gasket.
Then turn the hob over insert it into the cut-out of the
furniture. Align the positioning symmetrically so that the
distances between the hob and the countertop is the
same on all sides. (g. 5)
5
● The hob has a xed-mounted cable with a neutral contact and may only be connected to a
230 V ~ 50 Hz socket with grounding pin. Socket power circuit should be protected with a 16
A fuse.
