18
OPERATION
Turn o the appliance
The appliance operates when at least one
cooking zone is on. Touch and hold to
turn o the selected cooking zone and then
the appliance.
The letter "H" appears on the display to indi-
cate residual heat.
Switching o selected cooking zone
Selected cooking zone may be switched o as follows:
- touch to turn o the selected cooking zone
- simultaneously touch and sensors, or
- use sensor to reduce heat setting to "0."
When both cooking zones operate:
- touch to turn o the selected cooking zone
- touch briey to allow heat setting adjustment, and then:
- simultaneously touch and sensors, or
- use sensor to reduce heat setting to "0."
The letter "H" appears on the display to indicate residual heat.
The cooking heat setting can be now changed at any moment using the method described
above in the "Set the heat setting" section.
Automatic warm-up function
Each cooking zone is equipped with an automatic warm-up function. When this is activated,
then the given cooking zone is switched on at full power for a time depending on the heat
setting selected, and is then switched back to the heat setting originally set.
Activate the automatic warm-up function by setting the required heat setting by touching
the sensor rst. Then the heat setting “9” is displayed intermittently on the cooking zone
display (2) with the letter “A” for around 10 seconds.
If you start to select the heat setting within 10 seconds by touching the sensor eld, then
the automatic warm-up function is activated and the letter “A” is displayed intermittently with
the cooking zone's heat setting selected for as long as the function is activated.
The cooking heat setting can be now changed at any moment using the method described
above in the "Set the heating power" section”.
