Je bekijkt pagina 11 van 28
PRESSURE REGULATOR
0 The regulator installed in the rangetop is adjusted at the factory for 5" WC (natural gas) or 10" WC (L.P.) depending on the
customer’s request. Regulators must not be removed.
0 The regulator can withstand a maximum pressure of 1/2 PSIG (14" WC). If the line pressure is beyond this limit, a step-down
regulator will be required.
0 Any adjustment to regulators must be made ONLY BY QUALIFIED service personnel with proper test equipment.
GAS REQUIREMENTS
0 Ensure supplied gas matches the rangetop’s gas type.
0 Naturalgasconnectionis1/2"N.P.T.minimum1/2"diameterexline.
0 Natural gas inlet pressure to measure 7" to 10" W.C.
0 Propanegasconnectionis1/2"N.P.T.minimum1/2"diameterexline.
0 LP gas inlet pressure to measure 11" to 14" W.C.
0
A step-down regulator in additon to the regulator provided with the LP rangetop is required at the LP (Propane) source to
limit pressure to a maximum of 14" W.C.
Check that all gas connections are properly sealed with a suitable gas joint compound.
TEST ALL JOINTS WITH A SOAPY WATER SOLUTION BEFORE LIGHTING THE BURNERS.
1. Turn ON the manual gas valve at the inlet side of the gas supply line.
2. Checkforgasleaksattheexiblecouplingorgasconnectorttingusingasolutionofonepartsoapandthreepartswater.
3. Sparinglysprayorbrushthesoapysolutionatthegasttings;activebubblingindicateslocationofgasleak.
4. Ifagasleakisdetectedturnoffthemanualgasvalveattheinletsideofthegasline.Callyourcertiedservicetechnician.
FLEXIBLE COUPLINGS, CONNECTORS AND CASTERS
0 Flexiblecouplingsand/orquick-disconnectttingsmustbeheavyduty,CSA/ULdesigncertiedofatleast1/2"NPTwith
suitable strain reliefs.
0 TheexibleconnectormustcomplywiththestandardforConnectors for Movable Gas Appliances, ANSI Z21.69-CSA 6.16
and any Quick-Disconnect Devices For Use With Gas Fuel Appliances should comply with ANSI Z21.41CSA 6.9.
0 AllconnectionsmustbesealedwithjointcompoundspeciedforLPorNaturalgas;andallconnectionsmustbetestedwith
a soapy water solution before using.
0 When disconnection of the restraint is necessary, make sure to reconnect the restraint after the rangetop has been returned to
its original position.
RANGETOP
Use & Care Manual
