ADJ Products, LLC - www.adj.com - Vizi Hex Wash7 Instruction Manual Page 12
5-Pin XLR DMX Connectors.
Some manufactures use 5-pin DMX-512 data cables for
DATA transmission in place of 3-pin. 5-pin DMX xtures may be implemented in a 3-pin
DMX line. When inserting standard 5-pin data cables in to a 3-pin line a cable adapter
must be used, these adapters are readily available at most electric stores. The chart
below details a proper cable conversion.
Conductor
5-Pin XLR Male (In)
3-Pin XLR Female (Out)
Pin 1
Pin 5 - Do Not Use
Pin 4 - Do Not Use
Pin 3
Pin 2
Pin 1
Pin 3
Pin 2
Not Used
Not Used
Data True (+ signal)
Data Compliment (- signal)
Ground/Shield
3-Pin XLR to 5-Pin XLR Conversion
Vizi Hex Wash7 DMX Set Up
