19
DMX SETUP
5-Pin XLR DMX Connectors. The VIZI CMY300 uses 5-pin DMX-512 data cables for DATA transmission
in place of a 3-pin. 5-pin DMX xtures may be implemented in a 3-pin DMX line. When inserting
standard 5-pin data cables in to a 3-pin line a cable adapter must be used, these adapters are readily
available at most electric stores. The chart below details a proper cable conversion.
3-Pin XLR to 5-Pin XLR Conversion
Conductor 3-Pin XLR Female (Out) 5-Pin XLR Male (In)
Ground/Shield Pin 1 Pin 1
Data Compliment (- signal) Pin 2 Pin 2
Data True (+ signal) Pin 3 Pin 3
Not Used Do Not Use
Not Used Do Not Use
DMX ADDRESSING
All xtures should be given a DMX starting address when using a DMX controller, so the correct xture
responds to the correct control signal. This digital starting address is the channel number from which
the xture starts to “listen” to the digital control signal sent out from the DMX controller. The assignment
of this starting DMX address is achieved by setting the correct DMX address on the digital control
display on the xture.
You can set the same starting address for all xtures or a group of xtures, or set different addresses for
each individual xture. Setting all xtures to the same DMX address will cause all xtures to react in the
same way, in other words, changing the settings of one channel will affect all the xtures simultaneously.
If you set each xture to a dierent DMX address, each unit will start to “listen” to the channel number
you have set, based on the quantity of DMX channels of each xture. That means changing the settings
of one channel will only aect the selected xture.
In the case of the VIZI CMY300, when in 21 channel mode you should set the starting DMX address of
the rst unit to 1, the second unit to 22 (21 + 1), the third unit to 43 (22 + 21), and so on. (See the chart
below for more details.)
Channel Mode Unit 1 Address Unit 2 Address Unit 3 Address Unit 4 Address
24 Channels 1 25 49 73
26 Channels 1 27 53 79
38 Channels 1 39 77 115
