11
INSTALLATION INSTRUCTIONS
DO NOT INSTALL THE FIXTURE IF YOU ARE NOT QUALIFIED TO DO SO!
Fixture MUST be installed following all local, national, and country commercial electrical and construction
codes and regulations.
Before rigging/mounting a single xture to any metal truss/structure or placing the xture(s) on any
surface, a professional equipment installer MUST be consulted to determine if the metal truss/structure
or surface is properly certied to safely hold the combined weight of the xture(s), clamps, cables, and
accessories.
Ambient operating temperature range is 32°F. (0°C) to 104°F. (40°C).
Fixture(s) should be installed in areas outside walking paths, seating areas, or away from areas where
unauthorized personnel might reach the xture by hand.
NEVER stand directly below the xture(s) when rigging, removing or servicing.
Overhead xture installation must always be secured with a secondary safety attachment, such as an
appropriately rated safety cable that can hold 10 times the weight of the xture. Allow approximately 15
minutes for the xture to cool down before serving.
CLAMP INSTALLATION
Screw one clamp via a M12 screw and nut into each Omega
Bracket. Insert the quick-lock fasteners of the Omega
Bracket into the respective holes of the xture base.
NOTE: The clamp must be attached to the Omega
Bracket before attaching the bracket to the xture.
Tighten the quick-lock fasteners fully clockwise. Pull
the safety-cable through the opening located on the
bottom of the unit and over the trussing system or a
safe xation spot. Insert the end in the carabiner, and
tighten the safety screw.
