4. Brief of Main Functions
The ADD/KILL Button changes the mode of the flash buttons. Normally the flash buttons
are in Add mode, whereas pressing any flash button will not kill other scenes, allowing
multiple scenes to be on at a time.
The Kill mode is activated by pressing the Add/Kill button and illuminating the LED
above it. Pressing any flash button will kill other active SCENE or Program.
In Kill Mode, the killed program does not stop running but can not output.
Add and Kill
1. In CHNS SCENES Mode, press down the button you can change the chasing
mode of programs between Single Mode and Mix Mode.
2.In Double Preset Mode, pressing down this button is equal to pushing Master Slider B
to the top.
3.In Single Preset Mode, this button could temporally record current output, with
Master Slider B to adjust.
Park
1. Enter the Double Preset Mode.
2. Push Channel Sliders 1 to 6 to the top and move Channel Sliders 19 to 24 to the
maximum.
3. Move Master A and B to the same level and push them to the same direction, you
will get a scene.
Example
1. Press Mode Select Button to enter A Double Preset Mode.
2. In this mode, Channel Sliders 1-24 and channel sliders 25-48 both control Channel
1-24.
3. Master A controls channel Slider 1-24 while Master B controls Channel Sliders 25-48.
4. In this Mode, no scene could be recorded.
Double Preset
.
Technical Specifications
34
29
48 channel conventional dimming console
Two scene operation (A/B faders)
4,300 programmable scenes- password protected
96 programmable chases (stacks)- password protected
24 x 4 pages = 96 total chases
Up to 1,000 scenes (steps) per chase
Solo & Pile On chase operation
Blind & Dark functions
48 individual channel faders
48 bump buttons
Midi In/Out Through
Tap Sync button for chase speed / fade override
Independent speed & fade control
Full-On button for 100% momentary output to all 48 channels
Bright LCD display
Use in conjunction with the ADJ or Elation: DP-DMX20L, CYBER
PAK, UNI PAK-II, UNI BAR, DP-415, DP-640, RMD620 &
RMD1210
Line level audio input and built in microphone for music sync
operation
Audio level fader
Fog Machine input and trigger button- compatible with ADJ
Vaporizer, MB-1000, Stallion, Vapor- Flow, Fog Storm-1200 &
1700
DMX Polarity switch (2-, 3+, / 2+, 3-)
Midi In, Out & Thru connectors
Power: 120V / 12V DC, 500mA. (Included) *Also available in 220V
