ADJ Products, LLC - www.adj.com - Saber Spot RGBW Instruction Manual Page 15ADJ Products, LLC - www.adj.com - Saber Spot RGBW Instruction Manual Page 14

Universal DMX Control: This function allows you to use a uni-

versal DMX-512 controller to control the colors, master dimmer and

strobe. A DMX controller allows you to create unique programs tai-

lored to your individual needs.

1. The Saber Spot RGBW has 12 DMX channel modes. See pages

17-26 for detailed description of the DMX values and traits.

2. To control your fixture in DMX mode, follow the set-up procedures

on pages 7-9 as well as the set-up specifications that are includ-

ed with your DMX controller.

3. Use the controller’s faders to control the various DMX fixture traits.

4. This will allow you to create your own programs.

5. Follow the instruction on page 9 to select your DMX channel

mode and set your desired DMX address.

6. For longer cable runs (more than a 100 feet) use a terminator on

the last fixture.

7. For help operating in DMX mode consult the manual included

with your DMX controller.

Show Mode: This mode allows either a single unit or several units

linked together to run a built-in program.

1. Press the MENU button until “Look” is displayed, and press

ENTER.

2. Press the UP or DOWN buttons to nd your desired show.

Saber Spot RGBW Operation Saber Spot RGBW

Primary-Secondary Set Up

Primary-Secondary Operation This function will allow you to

link up to 16 units together and operate without a controller. In a

Primary-Secondary set up, one unit will act as the controlling unit and

the others will react to the controlling units programs. Any unit can

act as a Primary

or as a Secondary.

1. Using approved DMX data cables, daisy chain your units togeth-

er via the XLR connector on the rear of the units. Remember the

Male XLR connector is the input and the Female XLR connector

is the output. The first unit

in the chain (primary) will use the

female XLR connector only - The last unit in the chain will use the

male XLR connector only. For longer cable runs we suggest a

terminator at the last fixture

2. On the Primary unit find your desired operating mode.

3. On the secondary units press the MENU button until

“Secondary” is displayed.

4. The Secondary units will now follow the Primary unit.

The Saber Spot RGBW Plus comes with 2 frost filters. Install the filter

in front of the lens and put the inlcuded retainer ring on top of the lens

to hold it in place.

Saber Spot RGBW Installing the Frost Lens
