29
SPECIFICATIONS
Optical:
• 300-Watt Quad RGBA C.O.B. LED (Chip On
Board - Red, Green, Blue & Amber)
• Life expectancy: rated at 50,000 hrs.
• Manual Zoom: 9, 15, 20, 25, 30, 35 or
40-degrees
• Zoom Ratio: 4.4:1
Photometrics:
• 5230 Lux (Zoomed In to 9°)
• 597 Lux (Zoomed Out to 40°)
• CRI: >90
Connection:
• DMX: 5-pin DMX In/Out
• With Wired Digital Communication Network
• Locking power In/Out connections
Control:
• DMX-512 and Aria X2 Wireless DMX / APP
• 6 DMX control modes: (4/5/9A/9B/13 & 15 Ch.
modes)
• RDM and RDM Net Compatible
• Primary/Secondary, stand-alone mode
• On-board manual control mode
Features:
• Aria X2 Compatible
• Linear white color temperature control (2300K
~ 9900K)
• Color Temperature Presets (2300K ~ 9900K)
• 4-button DMX menu display on rear panel
• OLED display
• Adjustable latch to manually change beam
angle
• Includes gel frame for diffusion lters (Diffusion
lter sold separately)
• 64 Built-in Color Macros
• 13 Built-in Internal Programs
• Strobe Rate: 0.6Hz to 7.5Hz
• Selectable Refresh Rates: 900Hz, 1000Hz,
1100Hz, 1200Hz, 1300Hz, 1400Hz, 1500Hz,
2500Hz, 4000Hz, 5000Hz, 10KHz, 15KHz,
20KHz, 25KHz
• Electronic Dimming: 0 - 100%
• 6 Dim Modes
• 4 Dim Curves
• On-board, color balance feature for each color
(RGBA)
IP20
4002034
Electrical:
• Power Draw Total (All LED’s @ Full On): 320W
• Power Consumption: 2.7A @ 120V/60Hz ; 1.5A
@ 220V/50Hz
• Multi-voltage operation: AC 100-240V, 50/60Hz
• Daisy chain: 2 xtures @ 120V; 4 xtures @
230V
• Fuse protected: 8A/250V
Ambient Temperature Range (For Use):
• -4° ~ 104°F (-20°C ~ 40°C)
Storage Temperature Range:
• -22° ~ 113°F (-30°C ~ 45°C)
Dimensions / Weight:
• Dimensions (LxWxH): 10.66” x 12.92” x 20.68”
/ 271 x 328 x 525mm
• Weight: 13.23 lbs. / 6kg.
IP Rating / Approvals:
• IP20, CE, FCC, ETL Approved
•
Specications and documentation subject to change
without notice.
