NOTE: In order for RDM to work properly, RDM enabled equipment must be used throughout
the entire system, including DMX data splitters and wireless systems.
Remote Device Management (RDM) is a protocol that sits on top of the DMX512 data standard for
lighting, and allows the DMX systems of the xtures to be modied and monitored remotely. This pro-
tocol is ideal for instances in which a unit is installed in a location that is not easily accessible.
With RDM, the DMX512 system becomes bi-directional, allowing a compatible RDM enabled control-
ler to send out a signal to devices on the wire, as well as allowing the xture to respond (known as a
GET command). The controller can then use its SET command to modify settings that would typically
have to be changed or viewed directly via the unit’s display screen, including the DMX Address, DMX
Channel Mode, and Temperature Sensors.
FIXTURE RDM INFORMATION:
Device ID Device Model ID RDM Code Personality ID
0000-FFFF 0010 1900
5Ch, 6Ch, 9Ch-A,
9Ch-B, 15Ch, 17Ch
Please be aware that not all RDM devices support all RDM features, and therefore it is important
to check beforehand to ensure that the equipment that you are considering includes all of the features
that you require.
The following parameters are accessible in RDM on this device:
RDM Parameter Code
Disc Unique Branch 0x0001
Disc Mute 0x0002
Disc Un Mute 0x0003
Supported Parameters 0x0050
Device Info 0x0060
Manufacturer Label 0x0081
Device Label 0x0082
Software Version Label 0x00C0
DMX Personality 0x00E0
DMX Start Address 0x00F0
Sensor Value 0x0201c
Curve 0x0343
Curve Description 0x0344
Identify Device 0x1000
DMX Fail Mode 0x0141
REMOTE DEVICE MANAGEMENT (RDM)
19
