LED Pixel 10C Installation
The LED Pixel 10C is fully operational in three different mounting
positions, hanging upside-down from a ceiling, hanging sideways on
trussing, or set on a at level surface. The unit should be mounted
using a mounting clamp (not provided), afxing it to the mounting
bracket that is provided with the unit. Always ensure that the unit is
rmly xed to avoid vibration and slipping while operating. Always
ensure that the structure to which you are attaching the unit is secure
and is able to support a weight of 10 times the unit’s weight. Also,
always use a safety cable that can hold 12 times the weight of the
unit when installing the xture.
The equipment must be installed by a professional, and it must be
installed in a place where it is out of the reach of people’s grasp.
ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 21 ADJ Products, LLC - www.adj.com - LED Pixel 10C User Manual Page 22
Channel Value Function
1 RED (TUBE 1 PIXEL 1)
0 - 255 0% - 100%
2 GREEN (TUBE 1 PIXEL 1)
0 - 255 0% - 100%
3 BLUE (TUBE 1 PIXEL 1)
0 - 255 0% - 100%
4 RED (TUBE 1 PIXEL 2)
0 - 255 0% - 100%
5 GREEN (TUBE 1 PIXEL 2)
0 - 255 0% - 100%
6 BLUE (TUBE 1 PIXEL 2)
0 - 255 0% - 100%
7 RED (TUBE 1 PIXEL 3)
0 - 255 0% - 100%
8 GREEN (TUBE 1 PIXEL 3)
0 - 255 0% - 100%
*Channels 9-472 Continues the same RGB Tube Pixel pattern*
473 GREEN (TUBE 10 PIXEL 14)
0 - 255 0% - 100%
474 BLUE (TUBE 10 PIXEL 14)
0 - 255 0% - 100%
475 RED (TUBE 10 PIXEL 15)
0 - 255 0% - 100%
476 GREEN (TUBE 10 PIXEL 15)
0 - 255 0% - 100%
477 BLUE (TUBE 10 PIXEL 15)
0 - 255 0% - 100%
478 RED (TUBE 10 PIXEL 16)
0 - 255 0% - 100%
479 GREEN (TUBE 10 PIXEL 16)
0 - 255 0% - 100%
480 BLUE (TUBE 10 PIXEL 16)
0 - 255 0% - 100%
LED Pixel 10C 480 Channel - DMX Values & Functions
LED Pixel 10C Connection & Linking
