11
INSTALLATION
CLAMP MOUNTING
This fixture features mounting holes for the attachment of Omega clamps, both on the mounting yoke
and on the rear panel. When mounting the fixture to a truss or any other suspended structure, be sure
to secure an appropriate rated clamp (not included) to each Omega bracket. Insert a bolt of appropri-
ate size through the bottom of the mounting clamp and the central hole on the mounting bracket, and
secure them together with a matching nut. Then insert the twist lock fasteners of the Omega bracket
into the mounting holes on the fixture, and twist to secure in place. Additionally, a safety cable of the
appropriate weight rating should be secured to the provided location at near the base of the mounting
yoke, to the left of the control panel.
SAFETY CABLE:
ALWAYS ATTACH A SAFETY CABLE WHENEVER INSTALLING THIS FIX-
TURE IN A SUSPENDED ENVIRONMENT TO ENSURE THAT THE FIXTURE
WILL NOT FALL IF THE CLAMP FAILS.
MOUNTING
CLAMP
OMEGA
BRACKET
MOUNTING
YOKE
SAFETY
CABLE
LOOP
