ADJ Products, LLC - www.adj.com - Jolt 300 User Manual Page 8
Jolt 300 Installation
Screw one clamp via a M12 screw and nut into the Omega bracket. Insert the quick-lock fasteners of the
Omega bracket’s into the respective holes on the bottom of the Jolt 300. Tighten the quick-lock
fasteners fully clockwise. Pull the safety cable through the Safety Loop located on the bottom of the
unit and over the trussing system or a safe xation spot. Insert the end in the carabine and tighten
the safety screw.
NOTICE: The suitable enviromental temperature for this lighting xture is between -25˚ C to 45˚ C.
Do not place this lighting xture in an enviroment where the temperatures are under or above the
temperatures stated above. This will allow the xture to run at its best and help prolong the xture
life.
1. 2.
Yoke
Yoke
Attachment Point
YOKE ATTACHMENT
Yoke
Attachment Point
1. 2.
Omega Bracket
Omega Bracket
Attachment Points
Safety Cable
Safety Cable
Attachment Point
OMEGA BRACKET & SAFETY CABLE ATTACHMENT
