11
SAFETY CABLE:
ALWAYS ATTACH A SAFETY CABLE WHENEVER INSTALLING THIS FIXTURE IN A
SUSPENDED ENVIRONMENT TO ENSURE THAT THE FIXTURE WILL NOT FALL IF
THE CLAMPS FAIL.
INSTALLATION GUIDELINES
CLAMP INSTALLATION
To suspend this fixture from a truss or other elevated installation, begin by attaching appropriately
rated mounting clamps to each of the included Omega brackets. Align the hole on the mounting
clamp with the hole on the Omega bracket, then insert an appropriately rated bolt through both
holes and secure in place with a matching washer and nut, as shown in the image below. Use the
twist-lock fasteners on the Omega bracket to secure the mounting clamp and Omega bracket
assembly to the mounting points on the underside of the fixture’s base. Please note that two
(2) mounting clamps and two (2) Omega brackets are required install the fixture safely and
securely.
Secure a separate SAFETY CABLE of the appropriate weight rating to the safety cable loop located
on the underside of the fixture’s base. Never use the carrying handles or location other than the
designated safety cable loop for the attachment of the safety cable.
SAFETY CABLE
ATTACHED TO
CABLE LOOP
