34
WiFly CONTROL
BEFORE SETTING THE WIRELESS CHANNEL ON ANY WIFLY FIXTURE, MAKE SURE
THE SOURCE WIFLY WIRELESS DMX TRANSCEIVER DEVICE IS OFF.
With this feature you are able to control the unit with DMX without the need of XLR cables. Your
DMX controller must be connected to a ADJ WiFly Transceiver to use this function. You are able to
communicate up to 2500 feet/760 meters (open line of sight).
1. Ensure the source WiFly wireless DMX Transceiver device is powered OFF.
2. Power ON the xture and using the control panel scroll to the PERSONALITY menu and press ENTER.
Use the UP and DOWN buttons to highlight the WIFLY SETTINGS submenu and press ENTER.
3. Using the UP and DOWN buttons, highlight ENABLE/DISABLE WIFLY. Press the ENTER button to
toggle between ENABLE & DISABLE. Press ENTER so that “Enable” is displayed.
4. Next highlight SET WIFLY CHANNEL and press ENTER. Use the UP and DOWN buttons to nd
your desired WiFly address and press ENTER to conrm.
NOTE: Erratic xture movement may occur if other WiFly wireless DMX products are in use in the same
area and are using the same WiFly wireless channel. When WiFly is enabled, the xture may immediately
start to respond to the DMX wireless signal from another WiFly wireless DMX Transceiver. Make sure to
know what WiFly wireless channels are being used in the area where the xture is being used.
ADJ WIFLY WIRELESS TRANSCEIVER only has 0-14 wireless channels, NO CH 15.
5. Press the MENU button to exit out of the WIFLY SETTINGS submenu. Press the UP button so that
SELECT SIGNAL is highlighted and press ENTER. Press the DOWN button to highlight WIFLY and
press ENTER. Select YES and press ENTER to conrm.
6. Set your desired DMX address in the DMX ADDRESS submenu of the DMX SETTINGS main
system menu. Set your desired DMX channel mode in the DMX CH MODE submenu of the DMX
SETTINGS main system menu.
7. Repeat this process for all WiFly compatible xtures in the WiFly wireless network, making sure all
xtures are assigned the same WiFly wireless channel
8. After all xtures in the WiFly wireless network have been set to the same WiFly wireless channel
and powered ON, power ON the source WiFly DMX Transceiver device.
9. Test all xtures connected to the WiFly wireless network to conrm proper functionality.
WIRELESS WIFLY INSTALLATION LOCATION GUIDELINES
For best results, position the xture so that the display screen is oriented in the direction of the transmitter
device or remote.
Wireless DMX signal can penetrate walls, glass, metal, and most objects. However, there are many
factors that can affect and/or interrupt the wireless DMX signal, one of which is people. Therefore, it
is highly recommended to position the wireless antenna a minimum of 9.8 ft. (3m) above audiences
and/or above ground level. Careful planning and testing of the selected installation location is critical to
ensure optimum and reliable wireless DMX operation.
