FS3000LED Gobo Installation
ADJ Products, LLC - www.adj.com - FS3000LED User Manual Page 10
In order to install and use the included Gobo Holder, follow the directions shown below:
2. Unscrew the retainer screw from the Gobo Holder.
3. Open up the Gobo Holder. Slide the Glass Gobo between the two halves of the Gobo Holder,
making sure that the Glass Gobo has been placed securely in its cutout.
4. Close the Gobo Holder. Replace and tighten the retainer screw.
1. Remove the Gobo Holder from its slot. The Gobo Holder handle is the ring-shaped item located
just aft of the Iris Adjustment lever.
5. Re-insert the Gobo Holder back into its slot on the xture. Make sure that the retainer screw on
the Gobo Holder is facing backwards (towards the control screen).
