18
SYSTEM MENU
The xture includes an easy to navigate system menu control panel display where all necessary settings
and adjustments are made. During normal operation, pressing the MODE button once will access the
xture’s main menu. Once in the main menu, you can navigate through the different functions with the
UP and DOWN buttons. When you reach a eld that requires adjusting, press the ENTER button to
access that eld and use the LEFT and RIGHT buttons to adjust the eld. Pressing the ENTER button
once more will conrm your setting. You may exit the main menu at any time without making any
adjustments by pressing the MODE button.
To access the LCD Menu Control Display via the internal battery, press and hold the BATTERY
ICON button for 3 seconds. The LCD Menu Control Display will shut OFF automatically about 1
minute from the last button press.
LCD CONTROL PANEL LOCKOUT
When the Key Lock function is activated, the control panel will automatically lock after the time set
under the Display submenu “Screen Saver Delay”.
When the Key Lock function is set to ON, the control panel will lock. Press and hold the MODE button
for 3 seconds to unlock.
When the Key Lock function is set to ON1, the control panel will lock, and will not unlock without a
code. To unlock the display follow these steps:
1. Press the UP button, and the display will change to: (one * appears).
2. Press the DOWN button, and the display will change to: (two * appear).
3. Press the UP button, and the display will change to: (three * appear).
4. Press the DOWN button, and the display will change to: (four * appear).
5. Press the ENTER button, and the display will be unlocked.
If the button sequence was entered correctly, the display and control panel will unlock. If the button
sequence was entered incorrectly, the display will return to the DMX address display.
POWER IN
AC100-240V 50/60Hz
POWER OUT
MAX:100-240V 5A
DMX OUT DMX IN
NET OUT NET IN
FUSE:
T8A/250V
