31
GOBO REPLACEMENT
This unit features interchangeable gobos. Proceed with caution when changing gobos, as gobos are
fragile and can be easily bent, scratched, or otherwise damaged.
Caution! Never open the unit when in use. Always disconnect the main power before attempt-
ing to change the gobos.
1. Engage both the pan and tilt locks. Unscrew the four (4) screws that secure the cover to the
head, then remove the safety clip that attaches near the bottom of the head and remove the
cover.
2. Locate the gobo wheels and color wheels. They are positioned near the second large silver
thumb screw on each side of the head. Turn the color wheel to that the open slot is facing
towards you, and then turn the gobo wheel until the gobo you wish to replace is aligned with the
open slot of the color wheel.
Gobo being
changed is aligned
to open slot in
color wheel
Open slot in color
wheel pointing
towards user
