DMX SETUP
DMX ADDRESSING
All fixtures should be given a DMX starting address when operating with a DMX controller, in order to
ensure that the correct fixture responds to the correct control signal. This digital starting address is
the channel number from which the fixture starts to “listen” to the digital control signal sent out from
the DMX controller. The starting DMX address is configured by setting the correct DMX address on
the control panel display on the fixture.
You can set the same starting address for multiple fixtures, or set different addresses for each indi-
vidual fixture. Setting multiple fixtures to the same DMX address will cause all those fixtures to react
in the same way. In this case, please note that changing the settings of one channel will affect all the
fixtures simultaneously.
If you set each fixture to a different DMX address, each unit will start to “listen” to the channel num-
ber you have set, based on the quantity of DMX channels of each fixture. That means changing the
settings of one channel will only affect the selected fixture.
As an example, when operating this device in 4 channel mode, you should set the starting DMX
address of the first unit to 1, the second unit to 5 (1 + 4), the third unit to 9 (1 + 4 + 4), and so on.
(See the chart below for more details.)
Channel Mode Unit 1 Address Unit 2 Address Unit 3 Address Unit 4 Address
4 Channels
1 5 9 13
7 Channels
1 8 15 22
8 Channels
1 9 17 25
13 Channels
1 14 27 40
16 Channels
1 17 33 49
60 Channels
1 61 121 181
63 Channels
1 64 127 190
69 Channels
1 70 139 208
72 Channels
1 73 145 217
120 Channels
1 121 241 361
