ADJ Products, LLC - www.adj.com - Encore FR20 DTW User Manual Page 7
Encore FR20 DTW Barn Door & Gel Frame Attachment
1. Open lock and slide the Gel Frame
in from the top and into the slot located
closest to the unit (Slot 2).
3. Secure Lock
Lock Open
GEL FRAME WITH BARN DOOR
2. Slide the Barn Door in from the top,
in front of the Gel Frame. The Barn Door
will sit in the same slot as the Gel Frame
(Slot 2).
BARN DOOR ONLY
1. Open lock and slide the provided spacer
(not shown) in from the top and into the
1st and 2nd slots (see inset view below).
Spacer sits in Slot 1 & 2
Spacer
2. Slide the Barn Door in from the top,
in front of the Spacer. The Barn Door
will sit in the 1st slot.
3. Secure Lock
Lock Open
