12
INSTALLATION INSTRUCTIONS
OVERHEAD RIGGING
Overhead rigging requires extensive experience, including calculating working load limits, installation
material being used, and periodic safety inspection of all installation material and the fixture, among
other skills. If you lack these qualifications, DO NOT attempt the installation yourself. Improper
installation can result in bodily injury and property damage.
OMEGA BRACKET
The included Omega Bracket can be attached to either of the long edges (for a “horizontal”
orientation). The best edge to attach the bracket to will depend on desired installation. Follow the
installation steps below.
OMEGA BRACKET MUST BE USED WHEN CONNECTING FIXTURES TOGETHER!
1. Attach the Omega Bracket to the fixture using 2 of the 4 included interlocking pins.
2. To remove the interlocking pins, push in the spring-loaded pin, and turn clockwise or counter-
clockwise until it releases from the fixture.
3. Slide the bracket into the alignment holes on the fixture.
4. Insert 2 interlocking pins into the fixture holes, making sure the pins go completely through the
fixture and into the bracket. With the pins completely inserted, push the pins towards the fixture
and turn clockwise or counter-clockwise to lock into place.
5. Confirm both pins and the bracket are secure before mounting the fixture with an appropriately
rated professional grade rigging clamp.
