17
SPECIFICATIONS
Features:
• 19” Rack-mount DMX Controller
• DMX 512 & RDM protocol.
• 512 DMX channels.
• Control up to 32 intelligent xtures, up to 18 channels each
• 32 chases, each up to 100 steps, can run 5 chases simultaneously
• 32 programmable scenes
• Soft-patchable faders & control wheels
• 16 built-in effects generator. 9 for moving light and 7 for RGB LED xtures
• USB for data backup and rmware update.
Control:
• DMX512 and RDM
• RDM to set the DMX addresses and DMX channel mode of the xtures from controller
• 16 channel control faders
• Dedicated Pan/Tilt wheels (User Assignable)
• 16 Effects / Fixture select buttons
• Sound sensitivity digitally adjustable (0%-100%), built-in Mic.
• With Wired Digital Communication Network
Connections:
• 5pin XLR DMX Output
• Power Supply Input
• USB A Port
Operational Conditions:
• Use in dry location only
• Min. ambient temperature: 32°F (0°C)
• Max ambient temperature: 104°F (40°C)
• Humidity: <75%
• Allow 6” minimum between this controller and surrounding devices or wall
Storage Conditions:
• Store in a dry location
• Ambient storage temperature: 77°F (25°C)
Power:
• Power Supply: DC9V`12V 300mA min. (DC9V 1A PSU Included)
• Power Consumption: DC9V 165mA 1.5W, DC12V 16mA 2W
Dimensions & Weight:
• Length: 19” (482mm)
• Width: 5.2” (131mm)
• Height: 3.4” (87mm)
• Weight: 4.7lbs.(2.13kg.)
Certications & Rating:
• CE, cETLus (Pending), IP20
Specications are subject to change without notice.
