SPECIFICATIONS

OPTICAL:

• Light Source: 1x 200-Watt COB (Chip on Board),

RGBAL (Red, Green, Blue, Amber & Lime), LED

Engine

• LED Engine Life Rating: Approximately 50,000

hrs.

• CRI: >90

• Tunable White Color Temperature: 2300~9900K

• 80-degree beam angle

• Includes lens kit to change to 40-degrees or

50-degrees beam angle

FEATURES:

• Embedded Aria X2 Wireless Management

System

• Primary / Secondary Mode

• Flicker Free operation (No ﬂickering on camera)

• Produces powerful, smooth RGBAL color mixing

with rich palettes of color

• Scissor yoke allows xture to be mounted on

truss or set on the ground

• Optional Barn Doors (BAR001) sold separately

CONTROL:

• 10 DMX Channel modes (5CH, 8CH-A, 8CH-B,

9CH, 10CH-A, 10CH-B, 12CH, 13CH, 16CH,

20CH)

• Linear color temperature control via DMX

• Built-in color temperature presets accessible via

DMX

• 64 built-in color macros

• 4-button OLED digital DMX display on rear panel

• Compatible with the ADJ UC IR24 remote control

(included)

• LED pulse and strobe effect

• Electronic Dimming: 0 - 100%

• 6 selectable Dim Modes (Standard, Stage, TV,

Architectural, Stage 2 & Theatre)

• 4 selectable Dim Curves (Square, Linear, Inv.

Squa & S.Curve)

• Adjustable selectable Refresh Rate (14 presets

from 900 – 25,000Hz)

CONNECTIONS:

• 5-pin XLR connectors for DMX data linking (5-Pin

DMX only as of June 2023)

• Indoor locking power In & Out connections to

daisy chain power

ELECTRICAL:

• Auto sensing power supply: AC 100V/60Hz -

240V/50Hz

• Power Draw: 175W max

• Daisy chain up to 5 xtures (120V) or 10 xtures

(230V) maximum

DIMENSIONS / WEIGHT:

• Dimensions with bracket (LxWxH): 13” x 10.3” x

7.5” / 330mm x 261mm x 190mm

• Dimensions without bracket (LxWxH): 8.6” x 7.5”

x 7.5” / 219mm x 190mm x 190mm

• Weight: 9.45 lbs. / 4.30 kg.

ACCESSORIES:

• BAR001 - COB Cannon Wash Barn Doors

RATING / APPROVALS:

• cETLus | FCC

Specications and documentation subject to change

without notice.
