American DJ® - www.americandj.com - VioROLL LED Instruction Manual Page 10American DJ® - www.americandj.com - VioROLL LED Instruction Manual Page 9
VioROLL LED System Menu & Operation
Operating Modes: The VioROLL LED can operate in three dif-
ferent modes. This next section will detail the differences in the
operating modes.
• Sound Active mode -
The unit will react to sound.
• Show mode -
Select 1 of 12 preset shows to run.
• DMX control mode -
This function will allow you to control each individual fixtures traits
with a standard DMX-512 controller such as the Elation® Show
Designer.
™
ADDR - DMX Address Setting. See page 12 “Universal DMX
Control” for more information.
1. Press the MENU, UP, or DOWN buttons until “ADDR” is dis-
played, press ENTER.
2. A number between 1-512 will be displayed and ashing.
Press the UP or DOWN buttons to nd your desired address.
Press ENTER to set your desired DMX address.
CHND - This will let select your desired DMX Channel mode.
1. Press the MENU button until “CHND” is displayed, press
ENTER. Either “1CH” or “5CH” will be displayed
2. Press the UP or DOWN buttons to choose your desired DMX
mode and press ENTER to conm and exit.
SLND - This will let you set your lights as a master or slave in
a master/slave conguration. Please see page page 13 “Mas-
ter-Slave Operation” for more information.
1. Press the MENU button until “SLND” is displayed, press
ENTER. “MSTR”, “SL 1” or “SL 2” will be displayed.
2. Press the UP or DOWN buttons until your desired setting is
displayed, press ENTER to conm and exit.
SHND: SH 1 - SH 6 - Show modes 1 - 6 (Factory programs)
Show mode can be run with sound activity or without. For show
mode to run without sound activity turn sound activity off.
1. Press the MENU button until “SHND” is displayed, press
ENTER.
2. “SH X” will now be displayed, “X” representing a number
between 1-6. Shows 1-6 are preset shows. Press the UP or
DOWN buttons to nd your desired show.
3. Press ENTER, and then press and hold the MENU button for
at least 3 seconds to conrm.
Note: Once a show is running you can switch between shows
using the UP or DOWN buttons.
4. The optional UC3 Controller (not included) may be used to
control different functions including blackout.
SOUN - In this mode you can run in sound active mode.
1. Press the MENU button until “SOUN” is displayed, press
ENTER.
2. Either “ON” or “OFF” will now be displayed. Press the UP or
DOWN buttons to select one or the other.
3. When you have made your selection, press the ENTER, and
then press and hold the MENU button for at least 3 seconds to
conrm.
4. The optional UC3 Controller (not included) may be used to
control different functions including blackout.
BLND - Blackout or Stand by mode.
1. Tap the either the MENU button until “BLND” is displayed,
VioROLL LED System Menu & Operation
